Description
Most boost pedals just make everything louder. The QBoost takes a different approach, borrowing the sweepable feel of a wah circuit to let you target one specific band of frequencies and push it up to +12dB. That means you can carve a narrow, cutting mid spike for solos, add low-mid weight to fatten a thin single-coil, or lean on a particular frequency to drive your preamp harder without smearing the rest of your tone. It’s equally happy as an always-on voicing tool sitting near the front of your chain as it is a stomp-and-cut booster kicked in for choruses.
Operation is deliberately simple, with just two knobs doing the work:
- QFILTER – sweeps the center frequency you want to boost, across a Q range of 250Hz to 960Hz
- VOLUME – sets how much output you get from that chosen frequency band
Built into a compact steel enclosure sized for tight pedalboard real estate, the QBoost runs on standard 9-12VDC (center-negative) power and draws under 100mA at 9V, so it plays nicely with any multi-output supply. Input impedance sits at 1M Ohm or less, output impedance at 10K Ohm or less, keeping it transparent to whatever comes before or after it in your chain.
Specs:
- Power: 9-12VDC, negative tip
- Current draw at 9V: <100mA
- Input impedance: <=1M Ohm
- Output impedance: <=10K Ohm
- Max gain: +12dB
- Q range: 250Hz-960Hz
- Dimensions: 60mm W x 120mm L x 30mm H (2.3″ x 4.7″ x 1.1″)
- Weight: 0.2kg (0.4lbs)
